JACK K5E-UT-01GBX356 D/DRIVE 5.6MM UBT TOP AND BOTTOM COVERSEAM

Jack K5-UT-01GBX356 Advanced Top and Bottom Feed Cylinderbed Interlock Thread Trimmer (UT)
Pricing and Availability on Request
Contact Us for Quote

Why Buy from Us?

  • You are dealing with the official Jack UK Importing and Distributing Network
  • Your machine enquiry will be passed onto your local Jack dealer who will quote, setup, and install your new machines. As well as providing full after sales support and warranty
  • Our centralised distribution warehouse supplies Jack machinery to all Jack Traders, providing the best possible service and local contact for your sewing requirements

Description / JACK K5E-UT-01GBX356 D/DRIVE 5.6MM UBT TOP AND BOTTOM COVERSEAM

Jack K5-UT-01GBX356

Advanced Top and Bottom Feed Cylinderbed Interlock

Thread Trimmer (UT)

There are no jumps at the start of the seam and quality stitching is ensured on the fabric. The thread trimmer guarantees a stable performance and the occurrence of an occasional inconvenience, in which the thread cannot be cut, is greatly reduced.

Silent Thread Trimmer And Footlifter

A stepper motor has been inserted that electronically controls the presser foot lifter and thread trimmer, making it twice as powerful and significantly more silent and precise.

High Speed, High Performance

The normal sewing speed of the K5E is 4,500 rpm, compared to the 3,700 rpm of a normal machine, the efficiency increases by more than 21%. If the average monthly earnings are based on the amount produced, it will increase, as it is possible to produce more for the same amount of work hours.

Wide Fabric Adaptability

Ability to sew on thin fabrics, knits and up to 8 layers of fabric thickness, without any adjustment, while maintaining the beauty of the stitch.

Vocal Guide

Using the machine it will teach you the various functions itself, if there are errors it will notify you and by clicking the VOICE key it will suggest how to solve the problem, moreover with a single key you can return to the initial settings. (-UT only)

Single Motor Shaft

Reduces machine torque, seams are faster, more stable, more durable.

Optional Devices

Optional Devices

Industry 4.0 (Optional)

Thanks to the integrated WIFI module you can modify the parameters and control the productivity of the machine directly from the application. NB: a Jack gateway must be purchased for every 50 machines


Technical Specifications

Model Jack K5-UT-01GBX356
Needle UY128GAS 11-14#
Number of Needles 3
Number of Threads 5
Stitch Width (mm) 1.5-45
Stitch Length 5.6/6.4
Differential Ratio 0.8-1.3
Presser Foot Lifting Height (mm) 7
Max Speed (s.p.m) 500
Volume (mm) 670x445x595
Weight (kg) 52/62

Product Attachments

document-text
Jack K5 - Brochure (2.71 MB)
document-text
Jack K5-UT - - Parts Book (5.74 MB)

More Information

Part No JACKK5UT01GB356
Weight (KG) 90.000000
Manufacturer Jack
